Tiansheng Mechanical Crawler Self-propelled Fertilizer Spreader 2FZGB-8

Serial Number

Item

Unit

Specification

1

Model Name

/

2FZGB-8 Fertilizer Spreader

2

Structural Type

/

Box Type

3

Operation Method

/

Rear Throw

4

Hopper Inner Dimensions (Length × Width × Height)

mm

3297×(2100/1190)×1291

5

Hopper Capacity

m³

8

6

Maximum Payload

kg

7200

7

Matched Power Value (Range)

HP

120

8

Spreading Device Type

/

Rear-mounted Vertical Double Disc Spreading

9

Fertilizer Conveying Method

/

Hydraulic Chain Plate Push

10

Spreading Width

m

≥6

11

Gauge

mm

1700

12

Track Specifications

/

400×90×68

13

Number of Tracks

pcs

2

14

Safety Performance-Travel Brake

m

≤ 6

15

Pure Working Hour Productivity

hm²/h

1---3.5

16

Fertilizing Amount

kg/m²

0.04---5

17

Coefficient of Variation of Fertilizing Uniformity

/

≤ 30%

18

Maximum Height

mm

2400

19

Maximum Width

mm

2100

20

Maximum Length

mm

5480

21

Types of Fertilizer Spread

/

Organic Fertilizer

22

Implementation Identification Outline Standard

/

DG/T 106-2019
