Multi-disc rotary mower, tractor-mounted disc mower, alfalfa mower manufacturer

Product Introduction

The machine is connected to the rear suspension drawbar of the tractor and operates by the power take-off shaft. It has 3-6 high-speed rotating cutter discs, each with two blades, capable of high-speed operation of 0.6-2 hectares per hour, with high production efficiency.

The rotation of the 3-6 cutter discs of this machine is driven by gears instead of the traditional belt drive, resulting in good operational stability, low failure rate, and low maintenance cost.

Due to the use of spring suspension and belt under-rotation, the cutter bar is low, easy to raise and lower, can cut close to the ground, has a low stubble height, and has good ground contouring ability.

The cutter blades can be retracted when encountering large obstacles to avoid damage. The mower relies on the rotational force of the turntable to concentrate the grass in the middle for easy collection.

This machine features a reasonable, simple, compact, reliable structure and easy maintenance.

1. Drum mower working width is 1.3m-2.5m, mainly with 3 to 6 cutters, matching tractor power from 18HP to 90HP

2. Drum mowers are used for mowing grass, hay, alfalfa, corn stalks, rice straw, etc.

3. Drum mowers can cut heavy, high-yield crops smoothly without clogging, and can also cut light and thin grass.

4. The drum mower can be quickly raised for turning or transport without adjusting the 3-point hitch.

5. Drum mowers are suitable for a wide range of terrains and contours, even uneven rocky ground.

Tiansheng Machinery Multi-disc Rotary Forage Mower Parameters
