Sugarcane harvester

TSZ-5000 Sugarcane Harvester Parameter Description

Serial Number

Technical Features

Parameter Value

1

Engine Model

YTO LR4A3Z-22 (Non-road China Stage Ⅱ)

2

Diesel Engine Type

In-line, Water-cooled, Turbocharged

3

Number of Cylinders - Cylinder Bore × Piston Stroke

4-105×125 (mm)

4

Rated Power/Speed

70 kW / (2200 r/min) )

5

Maximum Torque Speed

1600～1800 (r/min)

6

Rated Operating Fuel Consumption Rate

≤242 (g/kW·h)

7

Maximum Torque Operating Fuel Consumption Rate

≤238 (g/kW·h)

8

Rated Operating Oil Consumption Rate

≤1.63   (g/kW·h)

9

Idle Speed

1000±30 (r/min)

10

Front Wheel Track

2675  mm

11

Front and Rear Wheelbase

2698 mm, 3098 mm

12

Front Tire, Rear Tire Model

18.4-26, 8.25R15 Agricultural Tires

13

Minimum Ground Clearance

450 mm

14

Maximum Arm Lift Height

5500 mm

15

Maximum Loading Height of Grabber

4300 mm

16

Maximum Distance from Front Wheel to Loading Surface

1460 mm

17

Loading Height at Maximum Distance from Front Wheel to Loading Surface

3120 mm

18

Maximum Opening Size When Grabber is Open

1500 mm

19

Minimum Inner Size When Grabber is Closed

810 mm

20

Maximum Lifting Weight

800 Kg

21

Overall Transportation Dimensions (Length x Width x Height)

5.5 x 3.2 x 2.9 (m)

22

Overall Weight

5000 Kg

23

Travel Speed

5 - 10 (km/h)

24

Climbing Ability

45%

25

System Voltage

24 V

26

Maximum Hydraulic System Operating Pressure

25 MPa

27

Operating Ambient Temperature

-10℃～40℃

28

Applicable Altitude

≤3500 m
